FPGA based Digital Filter Design for faster operations

Abstract

The reduced complexity design of the IIR filter is discussed in this paper. The use of the IIR filter has been variably increasing during the present times and they are real time applications. The filter complexity reduction is done to increase the usage of filters in FPGA. In this method, the coefficients are expressed in the form of 1’s and 0’s. The multiplied delays have been used which is used to scale down the complexity. Signal Flow Graph plays a critical role in identifying the difficult path. IIR Filter is programmed on basis of the Synchronous Data Flow and Pipelining. The Half Band IIR filters are used for high-performance applications. This design is processed to implement in FPGA which will result in higher speed and the cost will be variably decreased as well as the consumption of power. The entire process is implemented by using the Verilog language which reduces the complication and speeds up the whole process.
